TPS78227DDCR

TEXAS INSTRUMENTS  TPS78227DDCR  芯片, 稳压器, LDO, 固定, 2.7V, 150mA, TSOT-23-5

LDO（低压降）线性稳压器，150mA，2.0V 至 2.9V，Texas Instruments

### LDO（低压降）线性稳压器，Texas Instruments

低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

立创商城:
正 Vin=5.5V Vout=2.7V 150mA 40dB

德州仪器TI:
150-mA, nano-IQ, low-dropout voltage regulator with enable from -40°C to +125°C

得捷:
IC REG LINEAR 2.7V 150MA SOT23-5

欧时:
### LDO（低压降）线性电压调节器，150mA，2.0V 至 2.9V，Texas Instruments### LDO（低压降）线性电压调节器，Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

e络盟:
芯片, 稳压器, LDO, 固定, 2.7V, 150mA, TSOT-23-5

艾睿:
Use the LDO TPS78227DDCR linear regulator from Texas Instruments to maintain a constant output voltage. This device has a maximum power dissipation of 500 mW. Its typical dropout voltage at current is 0.13@150mA V. It has an overall accuracy of ±1 %. This voltage regulation device&s;s single output can produce a current up to 0.15 A. With a small input voltage of 2.2 V and a max of 5.5 V, this will supply sufficient power to your circuit. With a fixed output that has a voltage of 2.7 V, this is power management at its best. A load regulation of 2%Typ and line regulation of 1%Typ is necessary for providing a constant voltage level at your output. Its maximum power dissipation is 500 mW. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. The maximum dropout voltage is 0.25@150mA V. Its polarity is positive. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C.

安富利:
LDO Regulator Pos 2.7V 0.15A 5-Pin SOT T/R

Chip1Stop:
Single Channel LDO Single Fixed Output LDO, 150mA, 0.5μA Quiescent Current LDO Regulator Pos 2.7V 0.15A 5-Pin TSOT-23 T/R

Verical:
LDO Regulator Pos 2.7V 0.15A 5-Pin TSOT-23 T/R

Newark:
# TEXAS INSTRUMENTS  TPS78227DDCR  Fixed LDO Voltage Regulator, 2.2V to 5.5V, 130mV Dropout, 2.7Vout, 150mAout, TSOT-23-5

DeviceMart:
IC REG LDO 2.7V .15A TSOT23-5

Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 2.7V 150mA 5-SOT
