TLV1117-18IKVURG3

可调，固定低压差稳压器 ADJUSTABLE AND FIXED LOW-DROPOUT VOLTAGE REGULATOR

PMIC - 稳压器 - 线性 正 固定 1 输出 800mA TO-252-3

立创商城:
TLV1117-18IKVURG3

德州仪器TI:
800-mA, 15-V, linear voltage regulator

得捷:
IC REG LINEAR 1.8V 800MA TO252-3

艾睿:
Control the voltage level of your circuit with this LDO TLV1117-18IKVURG3 linear regulator from Texas Instruments. Its typical dropout voltage at current is 1.1@100mA|1.15@500mA|1.2@800mA V. This voltage regulation device&s;s single output can produce a current up to 0.8 A. The best way to provide power to your application is by using this, which needs a voltage of at least 3.2 V and no higher than 15 V. With a fixed output that has a voltage of 1.8 V, this is power management at its best. To produce a constant current at your output, supply your circuit with a load regulation of 0.4% and line regulation of 0.2%. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. Its polarity is positive. The maximum dropout voltage is 1.3@100mA|1.35@500mA|1.4@800mA V.

安富利:
LDO Regulator Pos 1.8V 0.8A 3-Pin2+Tab PFM T/R

Verical:
LDO Regulator Pos 1.8V 0.8A 3-Pin2+Tab PFM T/R

Newark:
# TEXAS INSTRUMENTS  TLV1117-18IKVURG3  Fixed LDO Voltage Regulator, 3.2V to 15V In, 1.2V Dropout, 1.8V/800mA Out, TO-252AA-3
