低功耗150 mA低压降线性稳压器 LOW-POWER 150-mA LOW-DROPOUT LINEAR REGULATORS
PMIC - 稳压器 - 线性 正 固定 1 输出 150mA SOT-23-5
得捷:
IC REG LINEAR 1.6V 150MA SOT23-5
立创商城:
TPS76316DBVR
德州仪器TI:
150-mA, 10-V, low-dropout voltage regulator with enable
贸泽:
LDO Voltage Regulators 1.6V 150mA LDO
艾睿:
If you need to maintain a steady voltage on your circuit, then this LDO TPS76316DBVR linear regulator from Texas Instruments is perfect for you! This device has a maximum power dissipation of 555 mW. It has an overall accuracy of ±3 %. Its typical dropout voltage at current is 0.3@150mA V. This voltage regulation device&s;s single output can produce a current up to 0.15 A. By only needing an input voltage of 2.7 V with a maximum of 10 V, this is the best way to control the power in your circuit. With a fixed output that has a voltage of 1.6 V, this is power management at its best. Maintain a constant voltage level with a line regulation of 0.07%/V. Its maximum power dissipation is 555 mW. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. Its polarity is positive.
安富利:
LDO Regulator Pos 1.6V 0.15A 5-Pin SOT-23 T/R
Chip1Stop:
Single Channel LDO Single Output LDO, 150mA, Fixed1.6V, Low Quiescent Current, Thermal Protection LDO Regulator Pos 1.6V 0.15A 5-Pin SOT-23 T/R
Verical:
LDO Regulator Pos 1.6V 0.15A 5-Pin SOT-23 T/R
Win Source:
IC REG LDO 1.6V 0.15A SOT23-5
DeviceMart:
IC REG LDO 1.6V .15A SOT-23-5
输出接口数 1
输入电压DC 10.0V max
输出电压 1.6 V
输出电流 150 mA
供电电流 100µA ~ 140µA
耗散功率 0.555 W
静态电流 80.0 µA
输出电容类型 Ceramic
跌落电压 0.3V @150mA
调节输出数 1
输入电压Max 10 V
输入电压Min 2.7 V
输出电压Min 1.6 V
输出电流Max 0.15 A
工作温度Max 125 ℃
工作温度Min -40 ℃
耗散功率Max 555 mW
精度 3 %
输入电压 2.7V ~ 10V
安装方式 Surface Mount
引脚数 5
封装 SOT-23-5
长度 2.9 mm
宽度 1.6 mm
高度 1.15 mm
封装 SOT-23-5
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPS76316DBVR TI 德州仪器 | 当前型号 | 当前型号 |
TPS76316DBVT 德州仪器 | 完全替代 | TPS76316DBVR和TPS76316DBVT的区别 |
TPS76316DBVTG4 德州仪器 | 类似代替 | TPS76316DBVR和TPS76316DBVTG4的区别 |
TPS76316DBVRG4 德州仪器 | 类似代替 | TPS76316DBVR和TPS76316DBVRG4的区别 |
