TPS77018DBVT

LDO（低压降）线性电压调节器，最大 100mA，1.0V 至 2.9V，Texas Instruments### LDO（低压降）线性电压调节器，Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

LDO（低压降）线性稳压器，最大 100mA，1.0V 至 2.9V，Texas Instruments

立创商城:
TPS77018DBVT

德州仪器TI:
50-mA, 10-V, low-IQ, low-dropout voltage regulator

得捷:
IC REG LINEAR 1.8V 50MA SOT23-5

欧时:
Texas Instruments TPS77018DBVT LDO 稳压器, 1.8 V输出, 50mA最大输出, 3%精确度, 2.7 → 10 V输入

e络盟:
固定电压稳压器, LDO, 2.7V至10V, 35mV压差, 1.8V输出, 50mA输出, SOT-23-5

艾睿:
If you need to maintain a steady voltage on your circuit, then this LDO TPS77018DBVT linear regulator from Texas Instruments is perfect for you! This device has a maximum power dissipation of 555 mW. It has an overall accuracy of ±3 %. Its typical dropout voltage at current is 0.035@50mA V. This voltage regulation device&s;s single output can produce a current up to 0.05 A. With a small input voltage of 2.7 V and a max of 10 V, this will supply sufficient power to your circuit. With a fixed output that has a voltage of 1.8 V, this is power management at its best. Operate at a constant current by utilizing the load regulation of 8mVTyp and line regulation of 0.04%/VTyp. Its maximum power dissipation is 555 mW. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. Its polarity is positive. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C.

安富利:
LDO Regulator Pos 1.8V 0.05A 5-Pin SOT-23 T/R

Chip1Stop:
Single Channel LDO Single Output LDO, 50mA, Fixed1.8V, Low Quiescent Current LDO Regulator Pos 1.8V 0.05A 5-Pin SOT-23 T/R

TME:
Voltage regulator; LDO, fixed; 1.8V; 0.05A; SOT23-5; SMD

Verical:
LDO Regulator Pos 1.8V 0.05A 5-Pin SOT-23 T/R

Newark:
# TEXAS INSTRUMENTS  TPS77018DBVT  Fixed LDO Voltage Regulator, 2.7V to 10V, 35mV Dropout, 1.8Vout, 50mAout, SOT-23-5
