TPS70625DBVT

TEXAS INSTRUMENTS  TPS70625DBVT  芯片, 稳压器, LDO, 固定, 2.5V, 0.15A, SOT-23-5

The is a 2.5V fixed output Linear Regulator designed for power-sensitive applications. A precision bandgap and error amplifier provides 2% accuracy over temperature. Quiescent current of only 1µA makes these devices ideal solutions for battery-powered, always-ON systems that require very little idle-state power dissipation. These devices have thermal-shutdown, current-limit and reverse-current protection for added safety. This regulator can be put into shutdown mode by pulling the EN pin low. The shutdown current in this mode goes down to 150nA, typical.

.

Reverse current protection

.

Supports 200mA peak output

.

245mV at 50mA Low dropout

.

Green product and no Sb/Br
