TPS78318DDCR

具有使能功能和 -40°C 至 +105°C 工作温度范围的 150mA、毫微级 IQ、低压降稳压器 5-SOT-23-THIN -40 to 105

PMIC - 稳压器 - 线性 正 固定 1 输出 150mA SOT-23-5

立创商城:
TPS78318DDCR

德州仪器TI:
150-mA, nano-IQ, low-dropout voltage regulator with enable from -40°C to +105°C

得捷:
IC REG LINEAR 1.8V 150MA SOT23-5

艾睿:
Keep calm and stay stable by implementing this LDO TPS78318DDCR linear regulator developed by Texas Instruments. This device has a maximum power dissipation of 500 mW. Its typical dropout voltage at current is 0.13@150mA V. It has an overall accuracy of ±2 %. This voltage regulation device&s;s single output can produce a current up to 0.15 A. Supply your circuit with sufficient power by implementing this, which requires a minimum input voltage of 2.2 V that does not exceed 5.5 V. With a fixed output that has a voltage of 1.8 V, this is power management at its best. Operate at a constant current by utilizing the load regulation of 1%Typ and line regulation of 1%Typ. Its maximum power dissipation is 500 mW. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 105 °C. Its polarity is positive.

安富利:
LDO Regulator Pos 1.8V 0.15A 5-Pin SOT T/R

Verical:
LDO Regulator Pos 1.8V 0.15A 5-Pin TSOT-23 T/R
