TPS78928DBVT

超低功耗低噪声100mA低压降线性稳压器 ULTRALOW-POWER LOW-NOISE 100-mA LOW-DROPOUT LINEAR REGULATORS

PMIC - 稳压器 - 线性 正 固定 1 输出 100mA SOT-23-5

得捷:
IC REG LINEAR 2.8V 100MA SOT23-5

立创商城:
正 Vin=10V Vout=2.8V 100mA 85dB@1kHz

德州仪器TI:
100-mA, 10-V, low-IQ, low-dropout voltage regulator with bypass & enable

贸泽:
LDO Voltage Regulators Ultralow-Power Low Noise100-mA

艾睿:
Make a theoretical system actual by providing stable voltages with this LDO TPS78928DBVT linear regulator from Texas Instruments. Its typical dropout voltage at current is 0.06@50mA|0.122@100mA V. This device has a maximum power dissipation of 555 mW. This voltage regulation device&s;s single output can produce a current up to 0.1 A. With a small input voltage of 2.7 V and a max of 10 V, this will supply sufficient power to your circuit. With a fixed output that has a voltage of 2.8 V, this is power management at its best. At a load regulation of 12mVTyp and line regulation of 0.04%/VTyp a constant current can be produced at the output of your circuit. Its maximum power dissipation is 555 mW. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. Its polarity is positive. The maximum dropout voltage is 0.125@50mA|0.245@100mA V.

安富利:
LDO Regulator Pos 2.8V 0.1A 5-Pin SOT-23 T/R

Verical:
LDO Regulator Pos 2.8V 0.1A 5-Pin SOT-23 T/R

DeviceMart:
IC REG LDO 2.8V .1A SOT-23-5
