低功耗低噪声150 mA低压降线性稳压器 LOW-POWER LOW-NOISE 150-mA LOW-DROPOUT LINEAR REGULATORS
PMIC - 稳压器 - 线性 正 固定 1 输出 150mA SOT-23-5
得捷:
IC REG LINEAR 2.7V 150MA SOT23-5
立创商城:
TPS76427DBVR
德州仪器TI:
150-mA, 10-V, low-dropout voltage regulator with bypass & enable
贸泽:
LDO Voltage Regulators 2.7V 150mA LDO
艾睿:
Make a theoretical system actual by providing stable voltages with this LDO TPS76427DBVR linear regulator from Texas Instruments. This device has a maximum power dissipation of 555 mW. It has an overall accuracy of ±3 %. Its typical dropout voltage at current is 0.3@150mA V. This voltage regulation device&s;s single output can produce a current up to 0.15 A. Using the part will provide the power your application needs by requiring a voltage only of 2.7 V and not exceeding a voltage of 10 V. With a fixed output that has a voltage of 2.7 V, this is power management at its best. To produce a constant current at your output, supply your circuit with a line regulation of 0.07%/V. Its maximum power dissipation is 555 mW. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. Its polarity is positive.
安富利:
LDO Regulator Pos 2.7V 0.15A 5-Pin SOT-23 T/R
Chip1Stop:
Single Channel LDO Single Output LDO, 150mA, Fixed2.7V, Low Noise, Low Quiescent Current LDO Regulator Pos 2.7V 0.15A 5-Pin SOT-23 T/R
Verical:
LDO Regulator Pos 2.7V 0.15A 5-Pin SOT-23 T/R
输出接口数 1
输入电压DC 10.0V max
输出电压 2.7 V
输出电流 150 mA
供电电流 100µA ~ 140µA
耗散功率 0.555 W
静态电流 80.0 µA
输出电容类型 Tantalum
跌落电压 0.3V @150mA
调节输出数 1
输入电压Max 10 V
输入电压Min 2.7 V
输出电压Min 2.7 V
输出电流Max 0.15 A
工作温度Max 125 ℃
工作温度Min 40 ℃
耗散功率Max 555 mW
精度 3 %
输入电压 2.7V ~ 10V
安装方式 Surface Mount
引脚数 5
封装 SOT-23-5
长度 2.9 mm
宽度 1.6 mm
高度 1.15 mm
封装 SOT-23-5
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPS76427DBVR TI 德州仪器 | 当前型号 | 当前型号 |
TPS76427DBVT 德州仪器 | 完全替代 | TPS76427DBVR和TPS76427DBVT的区别 |
TPS76427DBVRG4 德州仪器 | 类似代替 | TPS76427DBVR和TPS76427DBVRG4的区别 |
