TPA2038D1YFFR

3.2W单声道D类音频功率放大器，可选择增益和自动恢复短路保护 3.2 W Mono Class-D Audio Power Amplifier With Selectable Gain and Auto-Recovering Short-Circuit Protection

The TPA2038D1 is a 3.2 W into 4-ohm 10% THD high efficiency filter-free class-D audio power amplifier. The GAIN pin sets gain to either 6 dB or 12 dB.

Features like 95% efficiency, 1.5 mA quiescent current, 0.5 µA shutdown current, 81 dB PSRR, 20 µV output noise, and improved RF immunity make the TPA2038D1 class-D amplifier ideal for cellular handsets. A start-up time is within 4 ms with no turn-on pop.

The TPA2038D1 is available in a 1.21 mm x 1.16 mm, 0.4 mm pitch wafer chip scale package WCSP.
