TLE42962GV50HTSA1

INFINEON  TLE42962GV50HTSA1  固定电压稳压器, LDO, 5.5V至45V, 250mV压差, 5V输出, 30mA输出, SCT-595-5

LDO 稳压器，

Infineon 的一系列固定电压 LDO（低压降）线性稳压器

立创商城:
正 Vin=45V Vout=5V 30mA 60dB@100Hz

得捷:
IC REG LINEAR 5V 30MA SCT595-5

欧时:
Infineon TLE42962GV50HTSA1 LDO 稳压器, 4.8 → 5.2 V输出, 30mA最大输出, ±4%精确度

e络盟:
固定电压稳压器, LDO, 5.5V至45V, 250mV压差, 5V输出, 30mA输出, SCT-595-5

艾睿:
Having trouble maintaining a steady voltage? This LDO TLE42962GV50HTSA1 linear regulator from Infineon Technologies will give you control over the voltage levels of your circuit. It has an overall accuracy of ±4 %. Its typical dropout voltage at current is 0.25@20mA V. This voltage regulation device&s;s single output can produce a current up to 0.03 A. The best way to provide power to your application is by using this, which needs a voltage of at least 5.5 V and no higher than 45 V. With a fixed output that has a voltage of 5 V, this is power management at its best. By operating at a load regulation of 50mV and line regulation of 25mV you can provide a constant voltage at your output. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 150 °C. Its polarity is positive. The maximum dropout voltage is 0.3@20mA V.

Chip1Stop:
LDO Regulator Pos 5V 0.03A Automotive 5-Pin3+2Tab SCT-595

TME:
Voltage regulator; LDO, linear, fixed; 5V; 0.3A; PG-SCT595; SMD

Verical:
LDO Regulator Pos 5V 0.03A Automotive 5-Pin SCT-595 T/R

Newark:
# INFINEON  TLE42962GV50HTSA1  Fixed LDO Voltage Regulator, 5.5V to 45V, 250mV Dropout, 5Vout, 30mAout, SCT-595-5

Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 5V 30mA PG-SCT595-5
