TPS76427DBVT

低功耗低噪声150 mA低压降线性稳压器 LOW-POWER LOW-NOISE 150-mA LOW-DROPOUT LINEAR REGULATORS

Linear Voltage Regulator IC Positive Fixed 1 Output 150mA SOT-23-5

得捷:
IC REG LINEAR 2.7V 150MA SOT23-5

立创商城:
TPS76427DBVT

德州仪器TI:
150-mA, 10-V, low-dropout voltage regulator with bypass & enable

艾睿:
Stable power is ideal for better processing this LDO TPS76427DBVT linear regulator developed by Texas Instruments will help do so. It has an overall accuracy of ±3 %. Its typical dropout voltage at current is 0.3@150mA V. This device has a maximum power dissipation of 555 mW. This voltage regulation device&s;s single output can produce a current up to 0.15 A. This will operate at a minimum voltage of 2.7 V and a maximum voltage of 10 V, making it easy to control the power in your circuit. With a fixed output that has a voltage of 2.7 V, this is power management at its best. Using a line regulation of 0.07%/V is needed for a programmable DC power supply. Its maximum power dissipation is 555 mW. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. Its polarity is positive.

安富利:
LDO Regulator Pos 2.7V 0.15A 5-Pin SOT-23 T/R

Verical:
LDO Regulator Pos 2.7V 0.15A 5-Pin SOT-23 T/R
