2.25 MHz的300毫安降压转换器在2x2SON / TSOT23套餐 2.25 MHz 300 mA Step Down Converter in 2x2SON/TSOT23 Package
降压 开关稳压器 IC 正 固定 1.2V 1 输出 300mA 6-WDFN 裸露焊盘
得捷:
IC REG BUCK 1.2V 300MA 6SON
立创商城:
降压型 Vin=2V~6V Vout=1.2V 300mA
德州仪器TI:
1.2V / 300mA Step-Down Converter in 2x2mm SON/TSOT23 Package
贸泽:
开关稳压器 2.25MHz 300mA Step- Down Converter
艾睿:
Adjust the voltage level of your devices with this synchronous step down TPS62242DRVR DC to DC converter from Texas Instruments. This converter&s;s single output can produce a current up to 0.3 A. With a small input voltage of 2 V and a max of 6 V, this will supply sufficient power to your circuit. With a fixed output that has a voltage of 1.2 V, this is power management at its best. Maintain a constant voltage level with a load regulation of -0.5%/ATyp. Its switching regulator has a frequency of 2250Typ kHz. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This converter has an operating temperature range of -40 °C to 85 °C.
Chip1Stop:
Step-Down Regulator 2.25MHz 300mA Step-Down Converter in 2x2mm SON/TSOT23 Package Conv DC-DC Single Step Down 2V to 6V 6-Pin WSON EP T/R
Verical:
Conv DC-DC 2V to 6V Synchronous Step Down Single-Out 1.2V 0.3A 6-Pin WSON EP T/R
Newark:
# TEXAS INSTRUMENTS TPS62242DRVR DC-DC Switching Step-Down Converter, Adjustable, 6V/300mA out, SON-6
Win Source:
Buck Switching Regulator IC Positive Fixed 1.2V 1 Output 300mA 6-WDFN Exposed Pad
输出接口数 1
输出电压 1.2 V
输出电流 300 mA
供电电流 15.0 µA
静态电流 15.0 µA
调节输出数 1
开关频率 2.25 MHz
拓扑结构 Buck
输入电压Max 6 V
输入电压Min 2 V
输出电压Max 6 V
输出电压Min 1.2 V
输出电流Max 0.3 A
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 2 V
输入电压 2V ~ 6V
安装方式 Surface Mount
引脚数 6
封装 WSON-6
封装 WSON-6
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPS62242DRVR TI 德州仪器 | 当前型号 | 当前型号 |
TPS62242DRVT 德州仪器 | 类似代替 | TPS62242DRVR和TPS62242DRVT的区别 |
TPS62242DRVTG4 德州仪器 | 类似代替 | TPS62242DRVR和TPS62242DRVTG4的区别 |
TPS62242DRVRG4 德州仪器 | 类似代替 | TPS62242DRVR和TPS62242DRVRG4的区别 |
