TPS780330220DRVR

150mA，低压降稳压器，超低功耗， IQ 500nA的与引脚可选，双电平输出电压 150mA, Low-Dropout Regulator, Ultralow-Power, IQ 500nA with Pin-Selectable, Dual-Level Output Voltage

PMIC - 稳压器 - 线性 正 固定 输出 150mA 6-WSON（2x2）

得捷:
IC REG LIN 3.3V/2.2V 150MA 6WSON

立创商城:
TPS780330220DRVR

德州仪器TI:
150-mA, nano-IQ, low-dropout voltage regulator with pin-selectable, dual-level output voltage

艾睿:
Make a theoretical system actual by providing stable voltages with this LDO TPS780330220DRVR linear regulator from Texas Instruments. Its typical dropout voltage at current is 0.2@150mA V. This device has a maximum power dissipation of 1540 mW. It has an overall accuracy of ±2 %. This voltage regulation device&s;s single output can produce a current up to 0.15 A. It only needs a voltage of at least 2.2 V while not exceeding 5.5 V to effectively power your circuit. With a fixed output that has a voltage of 2.2|3.3 V, this is power management at its best. Your circuit has the capability to produce a constant current at its output by using a load regulation of 2% and line regulation of 1%. Its maximum power dissipation is 1540 mW. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. Its polarity is positive. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. The maximum dropout voltage is 0.25@150mA V.

安富利:
LDO Regulator Pos 3.3V2.2V 0.15A 6-Pin WSON EP T/R

Chip1Stop:
Single Channel LDO Single Output LDO, 150mA, Dual Level Fixed 3.3V or 2.2V with Vset Pin, 500nA Quiescent Current LDO Regulator Pos 3.3V2.2V 0.15A 6-Pin WSON EP T/R

Verical:
LDO Regulator Pos 2.2V3.3V 0.15A 6-Pin WSON EP T/R

DeviceMart:
IC REG LDO 3.3V/2.2V .15A 6-SON

Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 3.3V, 2.2V 150mA 6-SON 2x2
