TC1262-3.3VEBTR

TC1162 低压降电压稳压器### LDO（低压降）线性电压调节器，Microchip

TC1162 低压降电压稳压器

### LDO（低压降）线性稳压器，

欧时:
Microchip TC1262-3.3VEBTR LDO 稳压器, 3.3 V输出, 500mA最大输出, ±0.5%精确度, 2.7 → 6 V输入

得捷:
IC REG LINEAR 3.3V 500MA 3DDPAK

立创商城:
TC1262-3.3VEBTR

艾睿:
Stable voltages are always needed for sensitive systems implement this LDO TC1262-3.3VEBTR linear regulator from Microchip Technology. It has an overall accuracy of ±0.5 %. Its typical dropout voltage at current is 0.02@100uA|0.06@100mA|0.2@300mA|0.35@500mA V. This voltage regulation device&s;s single output can produce a current up to 0.5 A. This will operate at a minimum voltage of 2.7 V and a maximum voltage of 6 V, making it easy to control the power in your circuit. With a fixed output that has a voltage of 3.3 V, this is power management at its best. At a load regulation of 0.002%/mATyp and line regulation of 0.003%/VTyp a constant current can be produced at the output of your circuit. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. The maximum dropout voltage is 0.03@100uA|0.13@100mA|0.39@300mA|0.65@500mA V. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. Its polarity is positive.

Allied Electronics:
TC1262-3.3VEBTR, LDOVoltage Regulator, 500mA, 3.3V +/-0.5%, 2.7 to 6Vin, 3-Pin D2PAK
