开关控制器 AC Hi-Perf Current- Mode PWM Controller
升压,反激,正激 稳压器 正 输出 升压,升压/降压 - DC DC 切换控制器 IC 14-SOIC
得捷:
IC REG CTRLR MULT TOP 14SOIC
立创商城:
TL2843BQDRQ1
德州仪器TI:
Automotive Catalog high-performance current-mode PWM controller
贸泽:
开关控制器 AC Hi-Perf Current- Mode PWM Controller
艾睿:
Texas Instruments has the solution you need for your voltage control needs with their TL2843BQDRQ1 current controller. With an output that has a voltage of 5 V, this is power management at its best. Its single PWM output produces a current of 200 mA. This current mode controller supports boost|flyback|forward topology. You can operate this at a switching frequency of 500 kHz. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This current mode controller&s;s maximum duty cycle is 100 %. This current mode controller has a minimum operating temperature of -40 °C and a maximum of 125 °C. This device has a maximum of 30 V.
安富利:
Current Mode PWM Controller 5V 200mA 14-Pin SOIC T/R
Verical:
Current Mode PWM Controller 5V 200mA 14-Pin SOIC T/R
输出接口数 1
输出电压 5 V
输出电流 200 mA
调节输出数 1
上升时间 150 ns
开关频率 500 kHz
拓扑结构 Boost, Flyback, Forward
占空比 100 %
最大占空比 100 %
下降时间 150 ns
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 7.6V ~ 30V
安装方式 Surface Mount
引脚数 14
封装 SOIC-14
封装 SOIC-14
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TL2843BQDRQ1 TI 德州仪器 | 当前型号 | 当前型号 |
UC3842DG4 德州仪器 | 类似代替 | TL2843BQDRQ1和UC3842DG4的区别 |
UC3843DTRG4 德州仪器 | 类似代替 | TL2843BQDRQ1和UC3843DTRG4的区别 |
5962-8670408VPA 德州仪器 | 功能相似 | TL2843BQDRQ1和5962-8670408VPA的区别 |
