TPS76130DBVR

低功耗100mA低压降线性稳压器 LOW-POWER 100-mA LOW-DROPOUT LINEAR REGULATORS

PMIC - 稳压器 - 线性 正 固定 1 输出 100mA SOT-23-5

立创商城:
TPS76130DBVR

德州仪器TI:
100-mA, 16-V, low-dropout voltage regulator with reverse current protection

得捷:
IC REG LINEAR 3V 100MA SOT23-5

贸泽:
低压差稳压器 100mA 3V LDO

艾睿:
Stable voltages are always needed for sensitive systems implement this LDO TPS76130DBVR linear regulator from Texas Instruments. It has an overall accuracy of ±2 %. This device has a maximum power dissipation of 555 mW. Its typical dropout voltage at current is 0.001@0mA|0.17@100mA|0.12@50mA|0.04@10mA|0.007@1mA V. This voltage regulation device&s;s single output can produce a current up to 0.1 A. It only needs a voltage of at least 3.35 V while not exceeding 16 V to effectively power your circuit. With a fixed output that has a voltage of 3 V, this is power management at its best. To produce a constant current at your output, supply your circuit with a line regulation of 10mV. Its maximum power dissipation is 555 mW. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. Its polarity is positive. The maximum dropout voltage is 0.003@0mA|0.24@100mA|0.15@50mA|0.06@10mA|0.01@1mA V.

安富利:
LDO Regulator Pos 3V 0.1A 5-Pin SOT-23 T/R

Chip1Stop:
Single Channel LDO Single Output LDO, 100mA, Fixed3.0V, Low Quiescent Current, Thermal Protection LDO Regulator Pos 3V 0.1A 5-Pin SOT-23 T/R

Newark:
# TEXAS INSTRUMENTS  TPS76130DBVR  LDO Voltage Regulator, Fixed, 170 mV drop, 100 mA out

Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 3V 100mA SOT-23-5
