TPS71727DCKT

低噪声，高带宽PSRR低压降150mA线性稳压器 Low Noise, High-Bandwidth PSRR Low-Dropout 150mA Linear Regulator

Maintain a steady voltage level with this LDO linear regulator from Texas Instruments. Its typical dropout voltage at current is 0.17@150mA V. It has an overall accuracy of ±3 %. This device has a maximum power dissipation of 320 mW. This voltage regulation device"s single output can produce a current up to 0.15 A. This will operate at a minimum voltage of 2.5 V and a maximum voltage of 6.5 V, making it easy to control the power in your circuit. With a fixed output that has a voltage of 2.7 V, this is power management at its best. At a load regulation of 120uV/mATyp and line regulation of 125uV/VTyp your circuit is capable of maintaining a constant voltage level at your output. Its maximum power dissipation is 320 mW. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. Its polarity is positive. The maximum dropout voltage is 0.3@150mA V.
