5W+5W双BTL,D类音频放大器
放大器 IC 2 通道(立体声) D 类 PowerSSO-36 EPD
得捷:
IC AMP CLSS D STER 5W POWERSSO36
立创商城:
TDA7491LP13TR
贸泽:
Audio Amplifiers 20W Dual BTL Class D 18V VCC Audio Amp
艾睿:
Implement this TDA7491LP13TR class D amplifier from STMicroelectronics to amplify and buffer audio signals to drive a low impedance, inductive speaker load. Its maximum power dissipation is 1000Typ mW. It has a maximum load resistance of 8 Ohm. It has a differential input signal and a differential output signal. It has a 2-channel stereo output. This audio amplifier has a minimum operating temperature of -40 °C and a maximum of 85 °C. This device uses a single power supply.
安富利:
Audio Amp Speaker 2-CH Stereo 5W Class-D 36-Pin PowerSSO EP T/R
富昌:
TDA7491LP 系列 14 V 2 x 5 W 双 BTL D 类 音频放大器 - PowerSSO-36
Chip1Stop:
Audio Amp Speaker 2-CH Stereo 5W Class-D 36-Pin PowerSSO EP T/R
Verical:
Audio Amp Speaker 2-CH Stereo 5W Class-D 36-Pin PowerSSO EP T/R
力源芯城:
5W+5W双BTL,D类音频放大器
Win Source:
IC AMP AUD CLASS D BTL PWRSSO36
DeviceMart:
IC AMP AUD CLASS D BTL PWRSSO36
电路数 1
通道数 2
针脚数 36
耗散功率 1000 mW
输出功率 5 W
增益 32 dB
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 1000 mW
电源电压 5V ~ 14V
电源电压Max 14 V
电源电压Min 5 V
安装方式 Surface Mount
引脚数 36
封装 PowerSSO-36
高度 2.4 mm
封装 PowerSSO-36
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TDA7491LP13TR ST Microelectronics 意法半导体 | 当前型号 | 当前型号 |
TDA7491LP 意法半导体 | 类似代替 | TDA7491LP13TR和TDA7491LP的区别 |
