低噪声,高带宽PSRR低压降150mA线性稳压器 Low Noise, High-Bandwidth PSRR Low-Dropout 150mA Linear Regulator
PMIC - 稳压器 - 线性 正 固定 1 输出 150mA SC-70-5
得捷:
IC REG LINEAR 2.9V 150MA SC70-5
立创商城:
正 Vin=6.5V Vout=2.9V 150mA
德州仪器TI:
150-mA, high-PSRR, low-IQ, low-dropout voltage regulator with enable
艾睿:
Stable voltages are always needed for sensitive systems implement this LDO TPS71729DCKT linear regulator from Texas Instruments. Its typical dropout voltage at current is 0.17@150mA V. This device has a maximum power dissipation of 320 mW. It has an overall accuracy of ±3 %. This voltage regulation device&s;s single output can produce a current up to 0.15 A. Supply your circuit with sufficient power by implementing this, which requires a minimum input voltage of 2.5 V that does not exceed 6.5 V. With a fixed output that has a voltage of 2.9 V, this is power management at its best. Operate at a constant current by utilizing the load regulation of 120uV/mATyp and line regulation of 125uV/VTyp. Its maximum power dissipation is 320 mW. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. The maximum dropout voltage is 0.3@150mA V. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. Its polarity is positive.
安富利:
LDO Regulator Pos 2.9V 0.15A 5-Pin SC-70 T/R
Chip1Stop:
Single Channel LDO Single Output LDO, 150mA, Fixed 2.9V, High PSRR, Low Quiescent Current, Low Noise LDO Regulator Pos 2.9V 0.15A 5-Pin SC-70 T/R
Verical:
LDO Regulator Pos 2.9V 0.15A 5-Pin SC-70 T/R
DeviceMart:
IC REG LDO 2.9V .15A SC70-5
输出接口数 1
输出电压 2.9 V
输出电流 150 mA
耗散功率 0.32 W
静态电流 45.0 µA
输出电容类型 Ceramic
跌落电压 0.17V @150mA
调节输出数 1
输入电压Max 6.5 V
输入电压Min 2.5 V
输出电流Max 0.15 A
工作温度Max 125 ℃
工作温度Min -40 ℃
耗散功率Max 320 mW
精度 3 %
输入电压 ≤6.5 V
安装方式 Surface Mount
引脚数 5
封装 SC-70-5
封装 SC-70-5
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPS71729DCKT TI 德州仪器 | 当前型号 | 当前型号 |
TPS71729DCKR 德州仪器 | 完全替代 | TPS71729DCKT和TPS71729DCKR的区别 |
TPS71729DCKTG4 德州仪器 | 类似代替 | TPS71729DCKT和TPS71729DCKTG4的区别 |
TPS71729DCKRG4 德州仪器 | 功能相似 | TPS71729DCKT和TPS71729DCKRG4的区别 |
