钽DIPPED / RADIAL TANTALUM DIPPED/RADIAL
This solid tantalum capacitor from Kemet will hold its charge for a long period of time due to its low leakage current characteristic. Users like its straight wire form. It can withstand a voltage of 35 VDC. Its leakage current is 0.5 μA. This part has a pitch of 2.54 mm. This solid capacitor has a maximum operating temperature of 125 °C. This product is 7.1Max mm tall with a diameter of 4.5Max mm. The T350A105K035AS solid capacitor has a radial termination style. Its capacitance value is 1uF. It has a tolerance of 10%.
额定电压DC 35 V
电容 1 µF
等效串联电阻ESR 8 Ω
容差 ±10 %
产品系列 T350
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 35 V
安装方式 Through Hole
封装 Radial
引脚间距 2.54 mm
长度 7.1 mm
高度 7.1 mm
直径 4.50 mm
封装 Radial
引脚间距 2.54 mm
介质材料 Tantalum
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Bulk
RoHS标准 Non-Compliant
含铅标准 Contains Lead
REACH SVHC版本 2015/06/15
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
T350A105K035AS KEMET Corporation 基美 | 当前型号 | 当前型号 |
T350A105K035AT 基美 | 完全替代 | T350A105K035AS和T350A105K035AT的区别 |
T350A105K025AS 基美 | 功能相似 | T350A105K035AS和T350A105K025AS的区别 |
ECS-F1VE105K 松下 | 功能相似 | T350A105K035AS和ECS-F1VE105K的区别 |
