TPS79030DBVT

LDO（低压降）线性电压调节器，最大 100mA，3.0V 至 3.9V，Texas Instruments### LDO（低压降）线性电压调节器，Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

Stable voltages are always needed for sensitive systems implement this LDO linear regulator from Texas Instruments. Its typical dropout voltage at current is 0.057@50mA V. This device has a maximum power dissipation of 555 mW. This voltage regulation device"s single output can produce a current up to 0.05 A. This will operate at a minimum voltage of 2.7 V and a maximum voltage of 10 V, making it easy to control the power in your circuit. With a fixed output that has a voltage of 3 V, this is power management at its best. Operate at a constant current by utilizing the load regulation of 8mVTyp and line regulation of 0.04%/VTyp. Its maximum power dissipation is 555 mW. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. The maximum dropout voltage is 0.115@50mA V. Its polarity is positive.
