TPS70919DBVT

具有反向电流保护和使能功能的 150mA、30V、超低 IQ、低压降稳压器 5-SOT-23 -40 to 125

The TPS709xx series of linear regulators are ultralow, quiescent current devices designed for power-sensitive applications. A precision band-gap and error amplifier provides 2% accuracy over temperature.

Quiescent current of only 1 µA makes these devices ideal solutions for battery-powered, always-on systems that require very little idle-state power dissipation. These devices have thermal-shutdown, current-limit, and reverse-current protections for added safety.

得捷:
IC REG LINEAR 1.9V 150MA SOT23-5

立创商城:
TPS70919DBVT

德州仪器TI:
150-mA, 30-V, ultra-low-IQ, low-dropout voltage regulator with reverse current protection and enable

艾睿:
Never worry about components seeing unstable voltages again by implementing this LDO TPS70919DBVT linear regulator manufactured by Texas Instruments. Its typical dropout voltage at current is 0.245@50mA V. It has an overall accuracy of ±2 %. This voltage regulation device&s;s single output can produce a current up to 0.15 A. With a small input voltage of 2.7 V and a max of 30 V, this will supply sufficient power to your circuit. With a fixed output that has a voltage of 1.9 V, this is power management at its best. Using a load regulation of 20mVTyp and line regulation of 3mVTyp is needed for a programmable DC power supply. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 85 °C. Its polarity is positive.

安富利:
LDO Regulator Pos 1.9V 0.15A 5-Pin SOT-23 T/R

Chip1Stop:
LDO Regulator Pos 1.9V 0.15A 5-Pin SOT-23 T/R

TME:
Voltage regulator; LDO, fixed; 1.9V; 0.15A; SOT23-5; SMD; -40÷125°C
