250毫安,超低IQ ,快速瞬态响应,射频低压差线性稳压器 250mA, Ultralow IQ, Fast Transient Response, RF LOW-DROPOUT LINEAR REGULATOR
PMIC - 稳压器 - 线性 正 固定 输出 250mA 4-DSBGA(1x1)
得捷:
IC REG LINEAR 1.1V 250MA 4DSBGA
立创商城:
TPS72711YFFR
德州仪器TI:
250-mA, ultra-low-IQ, low-dropout voltage regulator with enable
艾睿:
Use this LDO TPS72711YFFR linear regulator from Texas Instruments to vary your voltage levels to your desired level. This device has a maximum power dissipation of 370 mW. Its typical dropout voltage at current is 0.065@100mA|0.13@200mA|0.163@250mA V. It has an overall accuracy of ±1Typ %. This voltage regulation device&s;s single output can produce a current up to 0.25 A. With a small input voltage of 2 V and a max of 5.5 V, this will supply sufficient power to your circuit. With a fixed output that has a voltage of 1.1 V, this is power management at its best. Your circuit has the capability to produce a constant current at its output by using a load regulation of 20uV/mATyp and line regulation of 8uV/VTyp. Its maximum power dissipation is 370 mW. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. Its polarity is positive. This voltage regulation device has an operating temperature range of -40 °C to 125 °C.
Chip1Stop:
Single Channel LDO 250mA, Ultra-Low IQ, Fast Transient Response, RF Low-Dropout Linear Regulator LDO Regulator Pos 1.1V 0.25A 4-Pin DSBGA T/R
Verical:
LDO Regulator Pos 1.1V 0.25A 4-Pin DSBGA T/R
Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 1.1V 250mA 4-DSBGA 1x1
输出接口数 1
输出电压 1.1 V
输出电流 250 mA
供电电流 110µA ~ 130µA
耗散功率 0.37 W
静态电流 9.00 µA
输出电容类型 Ceramic
跌落电压 0.13V @200mA,0.065V @100mA,0.163V @250mA
调节输出数 1
输入电压Max 5.5 V
输入电压Min 2 V
输出电压Min 1.1 V
输出电流Max 0.25 A
工作温度Max 125 ℃
工作温度Min -40 ℃
耗散功率Max 370 mW
精度 2 %
输入电压 2V ~ 5.5V
安装方式 Surface Mount
引脚数 4
封装 DSBGA-4
封装 DSBGA-4
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPS72711YFFR TI 德州仪器 | 当前型号 | 当前型号 |
TPS72711YFFT 德州仪器 | 类似代替 | TPS72711YFFR和TPS72711YFFT的区别 |
ADP151ACBZ-1.1-R7 亚德诺 | 功能相似 | TPS72711YFFR和ADP151ACBZ-1.1-R7的区别 |
