TEXAS INSTRUMENTS TPS3824-25DBVR 电压监控器, 高电平有效, 低电平有效复位, 1.1V-5.5V输入, SOT-23-5
Keep your circuit secure if your main processor goes out by using this microprocessor supervisory circuit from Texas Instruments. This device has a maximum power dissipation of 437 mW. Its maximum power dissipation is 437 mW. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This part has an operating temperature range of -40 °C to 85 °C. It has a typical reset threshold voltage of 2.25 V, with a minimum of 2.2 V and a maximum of 2.3 V. This device has a minimum operating supply voltage of 1.1 V and a maximum of 5.5 V.
电源电压DC 5.50V max
供电电流 0.025 mA
针脚数 5
耗散功率 0.437 W
静态电流 15.0 µA
阈值电压 2.25 V
复位电压Min 2.2 V
复位电压Max 2.3 V
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 437 mW
电源电压Max 5.5 V
电源电压Min 1.1 V
安装方式 Surface Mount
引脚数 5
封装 SOT-23-5
宽度 1.6 mm
封装 SOT-23-5
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
TPS3824-25DBVR TI 德州仪器 | 当前型号 | 当前型号 |
TPS3824-25DBVT 德州仪器 | 类似代替 | TPS3824-25DBVR和TPS3824-25DBVT的区别 |
TPS3824-25QDBVRQ1 德州仪器 | 类似代替 | TPS3824-25DBVR和TPS3824-25QDBVRQ1的区别 |
TPS3824-25DBVRG4 德州仪器 | 类似代替 | TPS3824-25DBVR和TPS3824-25DBVRG4的区别 |
