MPU 监控和重置电路,Texas Instruments,0.8V 至 2.99VTexas Instruments 微处理器电源电压监控和重置电路系列,具有固定阈值电压电平。### 微处理器电源电压监控和复位电路电源电压监测和监控电路,用于台式机、便携式计算机和笔记本电脑、测试和测量仪器、便携式电池供电设备和多输出电源。电源电压探测器 电源电压监控器 电源监控器 微处理器监控 微处理器电压监控器 微控制器复位电路
MPU 监控和重置电路,Texas Instruments,0.8V 至 2.99V
Texas Instruments 微处理器电源电压监控和重置电路系列,具有固定阈值电压电平。
### 微处理器电源电压监控和复位电路
电源电压监测和监控电路,用于台式机、便携式计算机和笔记本电脑、测试和测量仪器、便携式电池供电设备和多输出电源。
电源电压探测器
电源电压监控器
电源监控器
微处理器监控
微处理器电压监控器
微控制器复位电路
立创商城:
TPS3824-25DBVT
得捷:
IC SUPERVISOR 1 CHANNEL SOT23-5
德州仪器TI:
Active-high & active-low, voltage supervisor reset IC with watchdog & manual reset
欧时:
### MPU 监控和重置电路,Texas Instruments,0.8V 至 2.99VTexas Instruments 微处理器电源电压监控和重置电路系列,具有固定阈值电压电平。### 微处理器电源电压监控和复位电路电源电压监测和监控电路,用于台式机、便携式计算机和笔记本电脑、测试和测量仪器、便携式电池供电设备和多输出电源。电源电压探测器 电源电压监控器 电源监控器 微处理器监控 微处理器电压监控器 微控制器复位电路
贸泽:
监控电路 Supply Voltage Supervisor
艾睿:
This TPS3824-25DBVT microprocessor supervisory circuit from Texas Instruments works to keep your circuit safe if something happens to your main processor. This device has a maximum power dissipation of 437 mW. Its maximum power dissipation is 437 mW. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This device has a minimum operating supply voltage of 1.1 V and a maximum of 5.5 V. It has a typical reset threshold voltage of 2.25 V, with a minimum of 2.2 V and a maximum of 2.3 V. This part has an operating temperature range of -40 °C to 85 °C.
安富利:
Processor Supervisor 2.25V 0V to 5.8V 5-Pin SOT-23 T/R
Chip1Stop:
Supervisor, Reset IC and Sequencer Supply Voltage Supervisor w/Watchdog input, RESET, /RESET Processor Supervisor 2.25V 0V to 5.8V 5-Pin SOT-23 T/R
Verical:
Processor Supervisor 2.25V 1 Active High/Active Low/Push-Pull 5-Pin SOT-23 T/R
电源电压DC 1.10V min
供电电流 0.025 mA
耗散功率 437 mW
静态电流 15.0 µA
阈值电压 2.25 V
复位电压Min 2.2 V
复位电压Max 2.3 V
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 437 mW
电源电压Max 5.5 V
电源电压Min 1.1 V
安装方式 Surface Mount
引脚数 5
封装 SOT-23-5
长度 2.9 mm
宽度 1.6 mm
高度 1.15 mm
封装 SOT-23-5
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPS3824-25DBVT TI 德州仪器 | 当前型号 | 当前型号 |
TPS3824-25DBVR 德州仪器 | 类似代替 | TPS3824-25DBVT和TPS3824-25DBVR的区别 |
TPS3824-25QDBVRQ1 德州仪器 | 类似代替 | TPS3824-25DBVT和TPS3824-25QDBVRQ1的区别 |
