2× 75W多功能双电桥功率放大器，集成数字诊断 2 x 75W multifunction dual-bridge power amplifier with integrated digital diagnostics
This class D amplifier manufactured from STMicroelectronics will strengthen your audio sound. This audio amplifier can handle a current up to 8000 mA. Its maximum power dissipation is 86000 mW. It has a differential input signal and a differential output signal. It has a maximum load resistance of 4 Ohm. It has a 1-channel mono|2-channel stereo output. This audio amplifier has a temperature range of -55 °C to 150 °C. This device uses a single power supply.
输出电流 8 A
电路数 1
通道数 2
针脚数 27
耗散功率 86000 mW
共模抑制比 56 dB
输出功率 150 W
增益 26 dB
输出电流Max 8000 mA
工作温度Max 150 ℃
工作温度Min -55 ℃
耗散功率Max 86000 mW
共模抑制比Min 56 dB
电源电压 8V ~ 18V
电源电压Max 18 V
电源电压Min 8 V
安装方式 Through Hole
引脚数 27
封装 Flexiwatt-27
宽度 4.5 mm
封装 Flexiwatt-27
工作温度 -55℃ ~ 150℃ TJ
产品生命周期 Active
包装方式 Tube
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
