TPS73633DRBR

TEXAS INSTRUMENTS  TPS73633DRBR  固定电压稳压器, LDO, 1.7V至5.5V, 75mV压差, 3.3V输出, 400mA输出, SON-8

PMIC - 稳压器 - 线性 正 固定 输出 400mA 8-SON（3x3）

得捷:
IC REG LINEAR 3.3V 400MA 8SON

德州仪器TI:
400-mA, high-accuracy, ultra-low-dropout voltage regulator with reverse current protection & enable

e络盟:
TEXAS INSTRUMENTS  TPS73633DRBR.  芯片, 稳压器, LDO, 3.3V, 0.4A, SON-8, 整卷

艾睿:
Never worry about components seeing unstable voltages again by implementing this LDO TPS73633DRBR linear regulator manufactured by Texas Instruments. Its typical dropout voltage at current is 0.075@400mA V. It has an overall accuracy of ±0.5 %. This voltage regulation device&s;s single output can produce a current up to 0.4 A. The best way to provide power to your application is by using this, which needs a voltage of at least 1.7 V and no higher than 5.5 V. With a fixed output that has a voltage of 3.3 V, this is power management at its best. A load regulation of 0.002%/mATyp and line regulation of 0.01%/VTyp is necessary for providing a constant voltage level at your output. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. The maximum dropout voltage is 0.2@400mA V. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. Its polarity is positive.

安富利:
LDO Regulator Pos 3.3V 0.4A 8-Pin VSON EP T/R

Chip1Stop:
Single Channel LDO Single Output LDO, 400-mA, Fixed 3.3 V, Cap-Free, Low-Noise, Reverse Current Protection LDO Regulator Pos 3.3V 0.4A 8-Pin VSON EP T/R

Verical:
LDO Regulator Pos 3.3V 0.4A 8-Pin VSON EP T/R

Newark:
# TEXAS INSTRUMENTS  TPS73633DRBR  Fixed LDO Voltage Regulator, 1.7V to 5.5V, 75mV Dropout, 3.3Vout, 400mAout, SON-8

Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 3.3V 400mA 8-SON Exposed Pad 3x3

DeviceMart:
IC REG LDO 3.3V .4A 8-SON
