TL783CKTTR

TEXAS INSTRUMENTS  TL783CKTTR  芯片, 可调高电压稳压器, D2PAK-3, 整卷

TL783 线性稳压器，Texas Instruments

Texas Instruments TL783 系列是正线性电压调节器，用于电压和电流可编程调节。 此三端可调高电压稳压器可通过 DMOS 输出晶体管提供 700 mA 输出电流，具有从 1.25 V 到 125 V 的电压范围。 这些稳压器提供电流限制、热关闭及输入过压保护。 设计用于无法使用标准双极稳压器的高电压应用。

可调输出：1.25 V 至 125 V，带外部电阻器分压器

输出电流：700mA

电压调节：输入 0.001%；输出：0.15%

输出晶体管安全工作区保护

纹波抑制：76 dB

得捷:
IC REG LIN POS ADJ 700MA DDPAK

欧时:
Texas Instruments TL783 系列 TL783CKTTR 线性稳压器, 21.5 → 150 V输入, 1.25 → 125 V输出 可调

立创商城:
正 Vin=125V Vout=1.25V~125V 700mA

德州仪器TI:
700-mA, 125-V, adjustable linear voltage regulator

e络盟:
TEXAS INSTRUMENTS  TL783CKTTR  芯片, 可调高电压稳压器, D2PAK-3, 整卷

艾睿:
Use this standard TL783CKTTR linear regulator from Texas Instruments to vary your voltage levels to your desired level. This voltage regulation device&s;s single output can produce a current up to 0.7 A. It only needs a voltage of at least 21.5 V while not exceeding 150 V to effectively power your circuit. With an adjustable output that has a voltage of 1.25 to 125 V, this is power management at its best. Users like the load regulation of 0.5% and line regulation of 0.01%/V. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This voltage regulation device has an operating temperature range of 0 °C to 125 °C. Its polarity is positive. The maximum dropout voltage is 20@700mA V.

安富利:
Standard Regulator Pos 1.25V to 125V 0.7A 4-Pin3+Tab TO-263 T/R

Chip1Stop:
Standard Voltage Regulator 3 Pin 750mA Adjustable Positive Voltage Regulator with 125VIN Standard Regulator Pos 1.25V to 125V 0.7A 4-Pin3+Tab TO-263 T/R

Verical:
Standard Regulator Pos 1.25V to 125V 0.7A 4-Pin3+Tab TO-263 T/R

Newark:
# TEXAS INSTRUMENTS  TL783CKTTR  Linear Voltage Regulator, Adjustable, 20V to 125V input, 1.25V to 125V/700 mA out, TO-263-3

Win Source:
IC REG LDO ADJ 0.7A DDPAK

DeviceMart:
IC REG LDO ADJ .7A D2PAK-3
