33uF ±20% 25V
模制 钽器 2917(7343 公制) 700 毫欧
得捷:
CAP TANT 33UF 20% 25V 2917
立创商城:
33uF ±20% 25V
艾睿:
Composed from tantalum solid this T491X336M025AT capacitor manufactured from Kemet has a high capacitance compared to other capacitors. It can withstand a voltage of 25 VDC. Its leakage current is 8.3 μA. This solid capacitor has a maximum operating temperature of 125 °C. This product is 7.3 mm long, 4 mm tall and 4.3 mm deep. It has a tolerance of 20%. Its capacitance value is 33uF.
安富利:
Cap Tant Solid 33uF 25V X CASE 20% 7.3 X 4.3 X 4mm SMD 7343-43 0.7 Ohm 125°C T/R
Chip1Stop:
Cap Tant Solid 33uF 25V X CASE 20% 7.3 X 4.3 X 4mm SMD 7343-43 0.7 Ohm 125 C T/R
Verical:
Cap Tant Solid 33uF 25V X CASE 20% 7.3 X 4.3 X 4mm SMD 7343-43 0.7 Ohm 125C Automotive T/R
Newark:
# KEMET T491X336M025AT Surface Mount Tantalum Capacitor, 33 µF, 25 V, T491 Series, ± 20%, 2917 [7343 Metric]
额定电压DC 25.0 V
电容 33 µF
等效串联电阻ESR 700 mΩ
容差 ±20 %
产品系列 T491
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 25 V
安装方式 Surface Mount
引脚数 2
封装公制 7343-43
封装 7343
长度 7.3 mm
宽度 4.3 mm
高度 4 mm
封装公制 7343-43
封装 7343
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
最小包装 500
寿命(小时) 2000h @85℃
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
T491X336M025AT KEMET Corporation 基美 | 当前型号 | 当前型号 |
T491D336K025AT 基美 | 类似代替 | T491X336M025AT和T491D336K025AT的区别 |
T491X336K025AT 基美 | 类似代替 | T491X336M025AT和T491X336K025AT的区别 |
T495X336K025ATE175 基美 | 类似代替 | T491X336M025AT和T495X336K025ATE175的区别 |
