TPS62150ARGTR 编带
Buck Switching Regulator IC Positive Adjustable 0.9V 1 Output 1A 16-VFQFN Exposed Pad
立创商城:
降压型 Vin=3V~17V Vout=900mV~6V 1A
得捷:
IC REG BUCK ADJUSTABLE 1A 16QFN
德州仪器TI:
3-17V 1A 3MHz Step-Down Converter with DCS-Control in 3x3 QFN Package
艾睿:
Adjust the voltage level of your devices with this step down TPS62150ARGTR DC to DC converter from Texas Instruments. This converter&s;s single output can produce a current up to 1 A. With a small input voltage of 3 V and a max of 17 V, this will supply sufficient power to your circuit. With a fixed output that has a voltage of 5 V, this is power management at its best. Operate at a constant current by utilizing the load regulation of 0.05%/ATyp and line regulation of 0.02%/VTyp. You can operate this at a switching frequency of 2500Typ kHz. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. This converter has a minimum operating temperature of -40 °C and a maximum of 85 °C.
安富利:
Conv DC-DC Single Step Down 3V to 17V 16-Pin QFN T/R
Verical:
Conv DC-DC 3V to 17V Synchronous Step Down Single-Out 5V 1A 16-Pin VQFN EP T/R
输出接口数 1
输出电压 5 V
输出电流 1 A
静态电流 17.0 µA
调节输出数 1
开关频率 2.5 MHz
拓扑结构 Buck
输入电压Max 17 V
输入电压Min 3 V
输出电压Max 6 V
输出电压Min 0.9 V
输出电流Max 1 A
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压Min 3 V
输入电压 17 V
安装方式 Surface Mount
引脚数 16
封装 VQFN-16
封装 VQFN-16
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPS62150ARGTR TI 德州仪器 | 当前型号 | 当前型号 |
TPS62150ARGTT 德州仪器 | 类似代替 | TPS62150ARGTR和TPS62150ARGTT的区别 |
TPS62151RGTT 德州仪器 | 类似代替 | TPS62150ARGTR和TPS62151RGTT的区别 |
TLV62150RGTR 德州仪器 | 类似代替 | TPS62150ARGTR和TLV62150RGTR的区别 |
