TPS61240IDRVRQ1

3.5 MHz的高效率升压转换器 3.5-MHz High Efficiency Step-Up Converter

升压 开关稳压器 IC 正 固定 5V 1 输出 500mA（开关） 6-WDFN 裸露焊盘

得捷:
IC REG BOOST 5V 500MA 6SON

立创商城:
升压型 Vin=2.3V~5.5V Vout=5V 500mA

德州仪器TI:
2.3-V to 5.5-V input range, 3.5-MHz fixed frequency 450-mA boost converter, AEC-Q100 qualified

贸泽:
开关稳压器 5V,400mA,4MHz Step- Up DC/DC Converter

艾睿:
Adjust the voltage level of your devices with this step up TPS61240IDRVRQ1 DC to DC converter from Texas Instruments. This converter&s;s single output can produce a current up to 0.5 A. The best way to provide power to your application is by using this, which needs a voltage of at least 2.3 V and no higher than 5.5 V. With a fixed output that has a voltage of 5 V, this is power management at its best. This converter is 90 % efficient. This part offers a switching frequency of 4000 kHz in order to work properly. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This converter has an operating temperature range of -40 °C to 85 °C.

安富利:
Conv DC-DC Single Step Up 2.3V to 5.5V 6-Pin WSON EP T/R

Chip1Stop:
Conv DC-DC 2.3V to 5.5V Step Up Single-Out 5V 0.5A Automotive 6-Pin WSON EP T/R

Verical:
Conv DC-DC 2.3V to 5.5V Synchronous Step Up Single-Out 5V 0.5A Automotive 6-Pin WSON EP T/R

DeviceMart:
IC REG BOOST SYNC 5V 0.45A 6SON
