TPS79433DGNR

超低噪声，高PSRR ，快速射频250 mA低压降线性稳压器 ULTRALOW-NOISE, HIGH PSRR, FAST RF 250-mA LOW-DROPOUT LINEAR REGULATORS

Having trouble maintaining a steady voltage? This LDO linear regulator from Texas Instruments will give you control over the voltage levels of your circuit. This device has a maximum power dissipation of 2600 mW. Its typical dropout voltage at current is 0.145@250mA V. It has an overall accuracy of ±3 %. This voltage regulation device"s single output can produce a current up to 0.25 A. Supply your circuit with sufficient power by implementing this, which requires a minimum input voltage of 2.7 V that does not exceed 5.5 V. With a fixed output that has a voltage of 3.3 V, this is power management at its best. Maintain a constant voltage level with a load regulation of 10mVTyp and line regulation of 0.05%/VTyp. Its maximum power dissipation is 2600 mW. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. This voltage regulation device has an operating temperature range of -40 °C to 85 °C. Its polarity is positive. The maximum dropout voltage is 0.2@250mA V.
