TPS79430DCQR

超低噪声，高PSRR ，快速射频250 mA低压降线性稳压器 ULTRALOW-NOISE, HIGH PSRR, FAST RF 250-mA LOW-DROPOUT LINEAR REGULATORS

PMIC - 稳压器 - 线性 正 固定 1 输出 250mA SOT-223-6

立创商城:
TPS79430DCQR

德州仪器TI:
250-mA, low-dropout voltage regulator with enable

得捷:
IC REG LINEAR 3V 250MA SOT223-6

艾睿:
Keep calm and stay stable by implementing this LDO TPS79430DCQR linear regulator developed by Texas Instruments. It has an overall accuracy of ±3 %. Its typical dropout voltage at current is 0.155@250mA V. This voltage regulation device&s;s single output can produce a current up to 0.25 A. Using the part will provide the power your application needs by requiring a voltage only of 2.7 V and not exceeding a voltage of 5.5 V. With a fixed output that has a voltage of 3 V, this is power management at its best. Your circuit has the capability to produce a constant current at its output by using a load regulation of 10mVTyp and line regulation of 0.05%/VTyp. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. Its polarity is positive. The maximum dropout voltage is 0.21@250mA V. This voltage regulation device has an operating temperature range of -40 °C to 85 °C.

安富利:
LDO Regulator Pos 3V 0.25A 6-Pin5+Tab SOT-223 T/R

Chip1Stop:
Single Channel LDO Single Output LDO, 250mA, Fixed3.0V, High PSRR, Low Noise LDO Regulator Pos 3V 0.25A 6-Pin5+Tab SOT-223 T/R

Verical:
LDO Regulator Pos 3V 0.25A 6-Pin5+Tab SOT-223 T/R

Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 3V 250mA SOT-223-6
