1.2A高效降压转换器,具有贪睡模式 1.2A High Efficient Step Down Converter with Snooze Mode
DESCRIPON
The TPS6208x devices are a family of high frequency synchronous step down converters. With an input voltage range of 2.3V to 6.0V, common battery technologies are supported. Alternatively, the device can be used for low voltage system power rails.
1FEATURES
• DCS-Control
TM
Architecture for Fast Transient
Regulation
• Snooze Mode for 6.5µA Ultra Low Quiescent Current
• 2.3V to 6.0V Input Voltage Range
• Supports High Output Capacitance up to 100µF
• 100% Duty Cycle for Lowest Dropout
• Power Save Mode for Light Load Efficiency
• Output Discharge Function
• Short Circuit Protection
• Power Good Output
• Thermal Shutdown
• Available in 2x2mm 8-Pin SON Package
APPLICATIONS
• Battery Powered Portable Devices
• Point of Load Regulators
• System Power Rail Voltage Conversion
输出接口数 1
输出电压 3.3 V
输出电流 1.2 A
静态电流 6.00 µA
调节输出数 1
开关频率 2 MHz
拓扑结构 Buck
输入电压Max 6 V
输入电压Min 2.3 V
输出电压Min 3.3 V
输出电流Max 1.2 A
工作温度Max 125 ℃
工作温度Min -40 ℃
输入电压 2.3V ~ 6V
安装方式 Surface Mount
引脚数 8
封装 WSON-8
封装 WSON-8
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPS62082DSGR TI 德州仪器 | 当前型号 | 当前型号 |
TPS62082DSGT 德州仪器 | 类似代替 | TPS62082DSGR和TPS62082DSGT的区别 |
