TPS2066CDGN-2

电源开关 IC - 配电 Dual CH Current Limiting Switch

* Dual Power Switch Family * Rated Currents of 0.5A, 1A, 1.5A, 2A * Accurate ±20% Current-limit Tolerance * Fast Overcurrent Response – 2 µs Typical * 70-mΩ Typical High-Side N-Channel MOSFET * Operating Range: 4.5 V to 5.5 V * Deglitched Fault Reporting FLTx * Selected Parts with TPS20xxC and without TPS20xxC-2 Output Discharge * Reverse Current Blocking * Built-in Softstart * Pin for Pin with Existing * Ambient Temperature Range: –40°C to 85°C

得捷:
IC PWR SWITCH N-CHAN 1:2 8MSOP

立创商城:
TPS2066CDGN-2

德州仪器TI:
2-ch, 1A loading, 4.5-5.5V, 70mΩ USB power switch, active-high, reverse blocking

贸泽:
电源开关 IC - 配电 Dual CH Current Limiting Switch

艾睿:
Use this usb power distribution switch TPS2066CDGN-2 USB powered Ethernet switch from Texas Instruments to control which one of your devices draws power. The best way to provide power to your application is by using this, which needs a voltage of at least 4.5 V and no higher than 5.5 V. Its current limit is 1.61 A. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. This USB powered network switch has a minimum operating temperature of -40 °C and a maximum of 85 °C.

安富利:
USB Power SW DIST Dual 5.5V 1.61A 8-Pin HVSSOP EP Tube

Chip1Stop:
USB Power SW DIST Dual 5.5V 1.61A 8-Pin HVSSOP EP Tube

Verical:
DIST Dual 5.5V 1.61A 8-Pin HVSSOP EP Tube
