TPS77301DGKR

LDO（低压降）线性电压稳压器，高达 250mA，Texas Instruments### LDO（低压降）线性稳压器，Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

可调 LDO（低压降）线性电压稳压器，高达 250mA，Texas Instruments

### LDO（低压降）线性稳压器，Texas Instruments

低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

欧时:
### 可调 LDO（低压降）线性电压稳压器，高达 250mA，Texas Instruments### LDO（低压降）线性稳压器，Texas Instruments低压降或 LDO 为线性电压稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 电压稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

得捷:
IC REG LIN POS ADJ 250MA 8VSSOP

立创商城:
TPS77301DGKR

德州仪器TI:
250-mA, 10-V, low-dropout voltage regulator with RESET with delay

艾睿:
This LDO TPS77301DGKR linear regulator from Texas Instruments acts like a variable resistor to maintain a steady voltage level. Its typical dropout voltage at current is 0.125@250mA V. It has an overall accuracy of ±2 %. This device has a maximum power dissipation of 412 mW. This voltage regulation device&s;s single output can produce a current up to 0.25 A. Use this part at voltages between 2.7 V and 10 V. With an adjustable output that has a voltage of 1.5 to 5.5 V, this is power management at its best. Your circuit has the capability to produce a constant current at its output by using a load regulation of 1mVTyp and line regulation of 0.005%/VTyp. Its maximum power dissipation is 412 mW. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. Its polarity is positive.

安富利:
LDO Regulator Pos 1.5V to 5.5V 0.25A 8-Pin VSSOP T/R

Verical:
LDO Regulator Pos 1.5V to 5.5V 0.25A 8-Pin VSSOP T/R

Win Source:
Linear Voltage Regulator IC Positive Adjustable 1 Output 1.5 V ~ 5.5 V 250mA 8-VSSOP
