TPS77328DGK

集成了复位或PG 250 mA的LDO稳压器 250-mA LDO REGULATORS WITH INTEGRATED RESET OR PG

PMIC - 稳压器 - 线性 正 固定 1 输出 250mA 8-VSSOP

立创商城:
TPS77328DGK

德州仪器TI:
250-mA, 10-V, low-dropout voltage regulator with RESET with delay

得捷:
IC REG LINEAR 2.8V 250MA 8VSSOP

贸泽:
LDO Voltage Regulators Fast Transient Response 250-mA

艾睿:
Use the LDO TPS77328DGK linear regulator from Texas Instruments to maintain a constant output voltage. This device has a maximum power dissipation of 412 mW. Its typical dropout voltage at current is 0.27@250mA V. It has an overall accuracy of ±2 %. This voltage regulation device&s;s single output can produce a current up to 0.25 A. The best way to provide power to your application is by using this, which needs a voltage of at least 2.7 V and no higher than 10 V. With a fixed output that has a voltage of 2.8 V, this is power management at its best. At a load regulation of 1mVTyp and line regulation of 0.005%/VTyp your circuit is capable of maintaining a constant voltage level at your output. Its maximum power dissipation is 412 mW. In order to ensure parts aren&s;t damaged by bulk packaging, this product comes in tube packaging to add a little more protection by storing the loose parts in an outer tube. Its polarity is positive. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. The maximum dropout voltage is 0.475@250mA V.

安富利:
LDO Regulator Pos 2.8V 0.25A 8-Pin VSSOP Tube

Chip1Stop:
LDO Regulator Pos 2.8V 0.25A 8-Pin VSSOP Tube

Verical:
LDO Regulator Pos 2.8V 0.25A 8-Pin VSSOP Tube
