宽范围电源控制器 WIDE-RANGE POWER-SUPPLY CONTROLLERS
升压 开关稳压器 IC 正 可调式 2.9V 1 输出 1A(开关) 8-SOIC(0.209",5.30mm 宽)
得捷:
IC REG BOOST ADJUSTABLE 1A 8SO
立创商城:
TL499ACPSR
德州仪器TI:
Wide-Range Power-Supply Controller
艾睿:
Many components require different DC voltage levels to operate properly. The step up TL499ACPSR DC voltage controller from Texas Instruments can safely provide the proper level. With an output that has a voltage of 2.9 to 30 V, this is power management at its best. Its output produces a current of 0.1Max A. This DC voltage controller has single output. This DC voltage controller has an input voltage of 4.5 to 32 V. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This DC voltage controller has an operating temperature range of -20 °C to 85 °C.
安富利:
DC DC Cntrlr Single-OUT Step Up 4.5V to 32V Input 8-Pin SOP T/R
Chip1Stop:
Step-Up Regulator Wide-Range Power-Supply Controller DC DC Cntrlr Single-OUT Step Up 4.5V to 32V Input 8-Pin SOP T/R
Verical:
DC DC Cntrlr Single-OUT Step Up 4.5V to 32V Input 8-Pin SOP T/R
DeviceMart:
IC REG BOOST ADJ 0.1A 8SO
Win Source:
Boost Switching Regulator IC Positive Adjustable 2.9V 1 Output 1A Switch 8-SOIC 0.209", 5.30mm Width
输出接口数 1
输出电压 2.9V ~ 30V
输出电流 100 mA
调节输出数 1
拓扑结构 Boost
输入电压Max 10 V
输入电压Min 1 V
输出电压Max 30 V
输出电压Min 2.9 V
输出电流Max 0.1 A
工作温度Max 85 ℃
工作温度Min -20 ℃
电源电压 1.1V ~ 10V
输入电压 1V ~ 10V
安装方式 Surface Mount
引脚数 8
封装 SOP-8
封装 SOP-8
工作温度 -20℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TL499ACPSR TI 德州仪器 | 当前型号 | 当前型号 |
TL499ACPS 德州仪器 | 类似代替 | TL499ACPSR和TL499ACPS的区别 |
TL499ACPSRG4 德州仪器 | 功能相似 | TL499ACPSR和TL499ACPSRG4的区别 |
TL499ACPSRE4 德州仪器 | 功能相似 | TL499ACPSR和TL499ACPSRE4的区别 |
