TPS73730DRBT

1A低压降稳压器具有反向电流保护 1A Low-Dropout Regulator with Reverse Current Protection

PMIC - 稳压器 - 线性 正 固定 输出 1A 8-SON（3x3）

立创商城:
TPS73730DRBT

德州仪器TI:
1-A, ultra-low-dropout voltage regulator with reverse current protection & enable

得捷:
IC REG LINEAR 3V 1A 8SON

贸泽:
低压差稳压器 Sgl Out LDO,1A,Fixed Rev Crnt Prot

艾睿:
Keep calm and stay stable by implementing this LDO TPS73730DRBT linear regulator developed by Texas Instruments. It has an overall accuracy of ±1 %. Its typical dropout voltage at current is 0.13@1A V. This voltage regulation device&s;s single output can produce a current up to 1 A. It only needs a voltage of at least 2.2 V while not exceeding 5.5 V to effectively power your circuit. With a fixed output that has a voltage of 3 V, this is power management at its best. A load regulation of 0.002%/mATyp and line regulation of 0.01%/VTyp is necessary for providing a constant voltage level at your output. This product will be shipped in tape and reel packaging so that components can be mounted effectively. Its polarity is positive. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. The maximum dropout voltage is 0.5@1A V.

安富利:
LDO Regulator Pos 3V 1A 8-Pin VSON EP T/R

Chip1Stop:
Single Channel LDO Single Output LDO, 1A, Fixed 3.3V, Reverse Current Protection LDO Regulator Pos 3V 1A 8-Pin VSON EP T/R

Verical:
LDO Regulator Pos 3V 1A 8-Pin VSON EP T/R

DeviceMart:
IC REG LDO 3V 1A 8SON
