TL750M05QKVURQ1

汽车低压差稳压器 AUTOMOTIVE LOW-DROPOUT VOLTAGE REGULATORS

DESCRIPON

The TL750M and TL751M series are low-dropout positive voltage regulators specifically designed for automotive applications. The TL750M and TL751M series incorporate onboard overvoltage and current-limiting protection circuitry to protect the devices and the regulated system. Both series are fully protected against load-dump and reverse-battery conditions. Load-dump protection is up to a maximum of 60 V at the input of the device. Low quiescent current, even during full-load conditions, makes the TL750M and TL751M series ideal for use in applications that are permanently connected to the vehicle battery.

FEATURES

• Qualified for Automotive Applications

• Customer-Specific Configuration Control Can Be Supported Along With Major-Change Approval

• Low Dropout Voltage, Less Than 0.6 V at 750 mA

• Low Quiescent Current

• TTL- and CMOS-Compatible Enable on TL751M Series

• Load-Dump Protection

• Overvoltage Protection

• Internal Thermal Overload Protection

• Internal Overcurrent-Limiting Circuitry
