TEXAS INSTRUMENTS TPS54319RTET 直流-直流开关降压逐步递减稳压器, 可调, 2.95V-6V输入, 800mV-4.5V输出, 3A输出, WQFN-16
降压 开关稳压器 IC 正 可调式 0.827V 1 输出 3A 16-WFQFN 裸露焊盘
得捷:
IC REG BUCK ADJUSTABLE 3A 16WQFN
立创商城:
降压型 Vin=2.95V~6V Vout=827mV~4.5V 3A
德州仪器TI:
2.95 V to 6 V input, 3 A, 2 MHz SWIFT™ synchronous step-down converter in a 3 mm x 3 mm QFN package
e络盟:
TEXAS INSTRUMENTS TPS54319RTET. 芯片, 同步降压直流/直流转换器, QFN16
艾睿:
Adjust the voltage level of your devices with this step down TPS54319RTET DC to DC converter from Texas Instruments. This converter&s;s single output can produce a current up to 3 A. The best way to provide power to your application is by using this, which needs a voltage of at least 2.95 V and no higher than 6 V. With an adjustable output that has a voltage of 0.8 to 4.5 V, this is power management at its best. Its switching regulator has a frequency of 300 to 2000 kHz. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This converter has a minimum operating temperature of -40 °C and a maximum of 150 °C.
安富利:
Conv DC-DC Single Step Down 2.95V to 6V 16-Pin WQFN EP T/R
Chip1Stop:
Step-Down Regulator 2.95V to 6V Input, 3A, 2MHz Synchronous Step-Down SWIFT? DCDC Converter Conv DC-DC Single Step Down 2.95V to 6V 16-Pin WQFN EP T/R
Verical:
Conv DC-DC 2.95V to 6V Synchronous Step Down Single-Out 0.8V to 4.5V 3A 16-Pin WQFN EP T/R
Newark:
# TEXAS INSTRUMENTS TPS54319RTET DC-DC Switching Buck Step Down Regulator, Adjustable, 2.95V-6Vin, 800mV-4.5Vout, 3Aout, WQFN-16
DeviceMart:
IC REG BUCK SYNC ADJ 3A 16WQFN
Win Source:
IC REG BUCK ADJ 3A SYNC 16WQFN
输出接口数 1
输出电压 0.8V ~ 4.5V
输出电流 3 A
针脚数 16
静态电流 360 µA
调节输出数 1
开关频率 2 MHz
拓扑结构 Buck
输入电压Max 6 V
输入电压Min 2.95 V
输出电压Max 4.5 V
输出电压Min 800 mV
输出电流Max 3 A
工作温度Max 150 ℃
工作温度Min -40 ℃
电源电压 2.95 V
输入电压 2.95V ~ 6V
安装方式 Surface Mount
引脚数 16
封装 WQFN-16
宽度 3 mm
封装 WQFN-16
工作温度 -40℃ ~ 150℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 消费电子产品, 电源管理
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPS54319RTET TI 德州仪器 | 当前型号 | 当前型号 |
TPS54319RTER 德州仪器 | 类似代替 | TPS54319RTET和TPS54319RTER的区别 |
TPS54388QRTERQ1 德州仪器 | 类似代替 | TPS54319RTET和TPS54388QRTERQ1的区别 |
BD9B300MUV-E2 罗姆半导体 | 功能相似 | TPS54319RTET和BD9B300MUV-E2的区别 |
