TPS7A3501DRVR

TPS7A3501DRVR 编带

* Regulates Input-to-Output Voltage: * User-Programmable Input-to-Output Voltage Regulation Range: 200 mV to 500 mV * Power-Supply Rejection Ratio: * 42 dB at 1 MHz * ≥ 32 dB 360 kHz to 3.9 MHz * Low-Noise Output: * 3.8 µVRMS 10 Hz to 100 kHz * Output Current: Up to 1 A * Output Voltage Range: 1.21 V to 4.5 V * Excellent Load Transient Response * Stable With Ceramic Capacitors as Low as 10 µF * Current Limit and Thermal Shutdown for Fault Protection * Available in a Low Thermal Resistance Package: 2-mm × 2-mm WSON-6 * Operating Temperature Range: –40°C to 125°C
