低静态电流可编程延迟监控电路 Low Quiescent Current, Programmable-Delay Supervisory Circuit
监控器 开路漏极或开路集电极 1 通道 6-WSON(2x2)
得捷:
IC SUPERVISOR 1 CHANNEL 6WSON
立创商城:
TPS3808G25DRVT
德州仪器TI:
Low-quiescent current supervisor with programmable delay & manual reset
艾睿:
Take control of a circuit with a failed core processor with the TPS3808G25DRVT microprocessor supervisory circuit from Texas Instruments. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This part has an operating temperature range of -40 °C to 125 °C. This device has a minimum operating supply voltage of 1.65 V and a maximum of 6.5 V. It has a typical reset threshold voltage of 2.33 V, with a minimum of 2.3183 V and a maximum of 2.341 V.
Chip1Stop:
Processor Supervisor 2.33V 0.4V to 5V 6-Pin WSON EP T/R
Verical:
Processor Supervisor 2.33V 0.4V to 5V 6-Pin WSON EP T/R
Newark:
# TEXAS INSTRUMENTS TPS3808G25DRVT Delay Supervisory Circuit, 1.7V-6.5V supply, 2.33V Threshold, 300 ms Delay, Active-Low Reset, SON-6
电源电压DC 1.70V min
供电电流 2.70 µA
静态电流 2.40 µA
阈值电压 2.33 V
复位电压Min 2.3183 V
复位电压Max 2.341 V
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压Max 6.5 V
电源电压Min 1.7 V
安装方式 Surface Mount
引脚数 6
封装 WSON-6
封装 WSON-6
工作温度 -40℃ ~ 125℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPS3808G25DRVT TI 德州仪器 | 当前型号 | 当前型号 |
TPS3808G25DRVR 德州仪器 | 完全替代 | TPS3808G25DRVT和TPS3808G25DRVR的区别 |
TPS3808G25DRVTG4 德州仪器 | 类似代替 | TPS3808G25DRVT和TPS3808G25DRVTG4的区别 |
TPS3808G25DRVRG4 德州仪器 | 功能相似 | TPS3808G25DRVT和TPS3808G25DRVRG4的区别 |
