D 68uF ±10% 16V
T495, Tantalum, MnO2 Tantalum, Commercial Grade, 68 uF, 10%, 16 VDC, SMD, MnO2, Molded, Low ESR, 70 mOhms, 7343, Height Max = 3.1mm
立创商城:
68uF ±10% 16V
艾睿:
The higher stability of this T495D686K016ATE070 solid tantalum capacitor from Kemet compared to its aluminum counterpart allows it to keep its properties through a variety of operating conditions. It can withstand a voltage of 16 VDC. This solid capacitor has a maximum operating temperature of 125 °C. Its leakage current is 10.9 μA. It has a tolerance of 10%. Its capacitance value is 68uF. This product is 7.3 mm long, 2.8 mm tall and 4.3 mm deep.
额定电压DC 16.0 V
电容 68 µF
等效串联电阻ESR 70.0 mΩ
容差 ±10 %
产品系列 T495
工作温度Max 125 ℃
工作温度Min -55 ℃
额定电压 16 V
安装方式 Surface Mount
引脚数 2
封装 7343
长度 7.3 mm
宽度 4.3 mm
高度 2.8 mm
封装 7343
介质材料 Tantalum
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Cut Tape CT
最小包装 500
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
T495D686K016ATE070 KEMET Corporation 基美 | 当前型号 | 当前型号 |
TPSD686K016R0070 艾维克斯 | 功能相似 | T495D686K016ATE070和TPSD686K016R0070的区别 |
TF3D686K016C0300 威世 | 功能相似 | T495D686K016ATE070和TF3D686K016C0300的区别 |
T495D686K016AHE070 基美 | 功能相似 | T495D686K016ATE070和T495D686K016AHE070的区别 |
