TPS71334DRCR

双路250mA输出，超低噪声，高PSRR ，低压差线性调节器，集成SVS Dual 250 mA Output, UltraLow Noise, High PSRR, Low-Dropout Linear Regulator with Integrated SVS

Linear Voltage Regulator IC Positive Adjustable Fixed 2 Output 250mA 10-VSON 3x3

立创商城:
TPS71334DRCR

德州仪器TI:
250-mA, dual-channel low-dropout voltage regulator with enable & RESET with delay

得捷:
IC REG LIN POS ADJ 250MA 10VSON

艾睿:
Never worry about components seeing unstable voltages again by implementing this LDO TPS71334DRCR linear regulator manufactured by Texas Instruments. Its typical dropout voltage at current is 0.125@250mA V. It has an overall accuracy of ±1.5 %. This device has a maximum power dissipation of 1920 mW. This voltage regulation device&s;s 2 outputs can produce a current up to 0.25 A. The best way to provide power to your application is by using this, which needs a voltage of at least 2.7 V and no higher than 5.5 V. With an adjustable|fixed output that has a voltage of 1.2 to 5.5|3.3 V, this is power management at its best. By operating at a load regulation of 0.8%/mATyp and line regulation of 0.05%/VTyp you can provide a constant voltage at your output. Its maximum power dissipation is 1920 mW. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. Its polarity is positive. The maximum dropout voltage is 0.23@250mA V.

安富利:
LDO Regulator Pos 1.2V to 5.5V3.3V 0.25A 10-Pin VSON EP T/R

Verical:
LDO Regulator Pos 1.2V to 5.5V3.3V 0.25A 10-Pin VSON EP T/R
