TPS71319DRCR

双路250mA输出，超低噪声，高PSRR ，低压差线性调节器，集成SVS Dual 250 mA Output, UltraLow Noise, High PSRR, Low-Dropout Linear Regulator with Integrated SVS

Linear Voltage Regulator IC 2 Output 250mA 10-VSON 3x3

得捷:
IC REG LIN POS ADJ 250MA 10VSON

立创商城:
TPS71319DRCR

德州仪器TI:
250-mA, dual-channel low-dropout voltage regulator with enable & RESET with delay

贸泽:
低压差稳压器 Dual 250 mA Output High PSRR

艾睿:
Never worry about components seeing unstable voltages again by implementing this LDO TPS71319DRCR linear regulator manufactured by Texas Instruments. Its typical dropout voltage at current is 0.125@250mA V. This device has a maximum power dissipation of 1920 mW. It has an overall accuracy of ±1.5 %. This voltage regulation device&s;s 2 outputs can produce a current up to 0.25 A. It only needs a voltage of at least 2.7 V while not exceeding 5.5 V to effectively power your circuit. With an adjustable|fixed output that has a voltage of 1.2 to 5.5|1.8 V, this is power management at its best. Your circuit has the capability to produce a constant current at its output by using a load regulation of 0.8%/mATyp and line regulation of 0.05%/VTyp. Its maximum power dissipation is 1920 mW. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. Its polarity is positive. The maximum dropout voltage is 0.23@250mA V.

安富利:
LDO Regulator Pos 1.2V to 5.5V1.8V 0.25A 10-Pin VSON EP T/R

Chip1Stop:
Dual Channel LDO Dual 250 mA Output, UltraLow Noise, High PSRR Low Dropout Linear Regulator with Integrated SVS LDO Regulator Pos 1.2V to 5.5V1.8V 0.25A 10-Pin VSON EP T/R

Verical:
LDO Regulator Pos 1.2V to 5.5V1.8V 0.25A 10-Pin VSON EP T/R

Newark:
# TEXAS INSTRUMENTS  TPS71319DRCR  LDO Voltage Regulator IC, Fixed/Adjustable, 2 Output, max 5.5 V in, 125 mV drop, 250 mA out, SON-10
