TLE4276GVATMA1

LDO Regulator Pos 2.5V to 20V 0.4A Automotive 6Pin5+Tab TO-263

PMIC - 稳压器 - 线性 正 可调式 1 输出 400mA P-TO220-5-122

得捷:
IC REG LIN POS ADJ 400MA TO220-5

艾睿:
This LDO TLE4276GVATMA1 linear regulator from Infineon Technologies is used to manipulate the voltage level of your circuit. Its typical dropout voltage at current is 0.25@250mA V. It has an overall accuracy of ±4 %. This voltage regulation device&s;s single output can produce a current up to 0.4 A. Use this part at voltages between 4.5 V and 40 V. With an adjustable output that has a voltage of 2.5 to 20 V, this is power management at its best. At a load regulation of 35mV and line regulation of 25mV your circuit is capable of maintaining a constant voltage level at your output. The maximum dropout voltage is 0.5@250mA V. Its polarity is positive. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 150 °C.

Chip1Stop:
LDO Regulator Pos 2.5V to 20V 0.4A Automotive 6-Pin5+Tab TO-263

Verical:
LDO Regulator Pos 2.5V to 20V 0.4A Automotive 6-Pin5+Tab TO-263 T/R

Win Source:
IC REG LIN POS ADJ 400MA TO220-5 / Linear Voltage Regulator IC Positive Adjustable 1 Output 400mA P-TO220-5-122
