3A高效同步降压转换器DCSA ?? ¢控制 3A High Efficient Synchronous Step Down Converter with DCS⢠Control
Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 3A 16-VFQFN Exposed Pad
得捷:
IC REG BUCK ADJUSTABLE 3A 16QFN
立创商城:
降压型 Vin=2.5V~6V Vout=800mV~6V 3A
德州仪器TI:
3A, 6V input, up to 97% efficiency, Synchronous Step Down Converter with DCS™ Control
艾睿:
Adjust the voltage level of your devices with this step down TPS62090RGTR DC to DC converter from Texas Instruments. This converter&s;s single output can produce a current up to 3 A. With a small input voltage of 2.5 V and a max of 6 V, this will supply sufficient power to your circuit. With an adjustable output that has a voltage of 0.8 to 6 V, this is power management at its best. This converter is 95 % efficient. Users like the load regulation of 0.04%/ATyp and line regulation of 0.016%/VTyp. You can operate this at a switching frequency of 2800Typ/1400Typ kHz. This product will be shipped in tape and reel packaging so that components can be mounted effectively. This converter has a minimum operating temperature of -40 °C and a maximum of 85 °C.
安富利:
Conv DC-DC Single Step Down 2.5V to 6V 16-Pin VQFN EP
Chip1Stop:
Conv DC-DC 2.5V to 6V Step Down Single-Out 0.8V to 6V 3A 16-Pin VQFN EP T/R
Verical:
Conv DC-DC 2.5V to 6V Synchronous Step Down Single-Out 0.8V to 6V 3A 16-Pin VQFN EP T/R
Win Source:
Buck Switching Regulator IC Positive Adjustable 0.8V 1 Output 3A 16-VFQFN Exposed Pad
DeviceMart:
IC REG BUCK SYNC ADJ 3A 16QFN
输出接口数 1
输出电压 0.8V ~ 6V
输出电流 3 A
静态电流 20.0 µA
调节输出数 1
开关频率 2.8 MHz
拓扑结构 Buck
输入电压Max 6 V
输入电压Min 2.5 V
输出电压Max 6 V
输出电压Min 0.8 V
输出电流Max 3 A
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 2.5 V
输入电压 6 V
安装方式 Surface Mount
引脚数 16
封装 VFQFN-16
封装 VFQFN-16
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
香港进出口证 NLR
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
TPS62090RGTR TI 德州仪器 | 当前型号 | 当前型号 |
TPS62090RGTT 德州仪器 | 类似代替 | TPS62090RGTR和TPS62090RGTT的区别 |
