TPS62751DSKT

高效率降压型转换器，用于USB应用 High Efficiency Step-Down Converter for USB Applications

series 转换器，USB 稳压器 IC 1 输出 10-SON（2.5x2.5）

立创商城:
Vout=800mV~5.1V

德州仪器TI:
2.25MHz, Step-Down Converter w/ Programmble Input Current Limits for USB powered Applications

得捷:
TPS62751 2.25MHZ, STEP-DOWN CONV

艾睿:
Adjust the voltage level of your devices with this step down TPS62751DSKT DC to DC converter from Texas Instruments. This converter&s;s single output can produce a current up to 1.5 A. The best way to provide power to your application is by using this, which needs a voltage of at least 2.9 V and no higher than 6 V. With an adjustable output that has a voltage of 0.8 to 5.1 V, this is power management at its best. This converter is 90min % efficient. Its switching regulator has a frequency of 2250Typ kHz. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This converter has an operating temperature range of -40 °C to 85 °C.

安富利:
Conv DC-DC Single Step Down 2.9V to 6V 10-Pin WSON EP T/R

Chip1Stop:
Step-Down Regulator 2.25MHz, 92% Efficiency Step-Down Converter with Forced PWM Mode Conv DC-DC Single Step Down 2.9V to 6V 10-Pin WSON EP T/R

Verical:
Conv DC-DC 2.9V to 6V Step Down Single-Out 0.8V to 5.1V 1.5A 10-Pin WSON EP T/R

DeviceMart:
IC CONVERTER, USB 10SON
