TPS76850QPWPR

快速瞬态响应， 1 -A低压差稳压器 FAST TRANSIENT RESPONSE, 1-A LOW-DROPOUT VOLTAGE REGULATORS

PMIC - 稳压器 - 线性 正 固定 输出 1A 20-HTSSOP

得捷:
IC REG LINEAR 5V 1A 20HTSSOP

立创商城:
TPS76850QPWPR

德州仪器TI:
1-A, 10-V, low-dropout voltage regulator with power good & enable

艾睿:
Use the LDO TPS76850QPWPR linear regulator from Texas Instruments to maintain a constant output voltage. Its typical dropout voltage at current is 0.23@1A V. It has an overall accuracy of ±2 %. This device has a maximum power dissipation of 4100 mW. This voltage regulation device&s;s single output can produce a current up to 1 A. Use this part at voltages between 2.7 V and 10 V. With a fixed output that has a voltage of 5 V, this is power management at its best. Your circuit has the capability to produce a constant current at its output by using a load regulation of 3mVTyp and line regulation of 0.01%/VTyp. Its maximum power dissipation is 4100 mW. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. Its polarity is positive.

安富利:
LDO Regulator Pos 5V 1A 20-Pin HTSSOP EP T/R

Verical:
LDO Regulator Pos 5V 1A 20-Pin HTSSOP EP T/R
